Technical Specication
Image Sensor
Sensor Type : 1/4” MegaPixel CMOS Sensor
Sensor Resolution : 1280 x 800 pixel
Minimum Illumination :
1 Lux (without LED)
0 Lux (with LED)
White LED
LED light distance up to 6m
Triggered by Auto PIR Sensor
Lens
Lens Type: Board Lens
Focal Length: f=3.6mm/F=2.3
View Angle: H: 55.7°, V: 36.5°
Video
Image Compression: H.264 / MPEG4 / MJPEG
Auto Exposure Control / Auto White Balance /
Auto Gain Control
Video Record
Store to PC: .asf
Store to SD card:.mp4
Image Resolution and Frame Rate:
1280 x 800: 30fps
640 x 400: 30fps
Audio
Audio Streaming: Two-way audio
Audio Code: G.711/AMR
Built-in MIC & Speaker
Zoom
Digital Zoom: 4x
Communication
Ethernet: one 10/100Mbps RJ-45
Supported Protocols: TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS,
SMTP, FTP, HTTP, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP,
Hardware
Flash ROM: 16MB
RAM:64M DDR
Interface & Buttons
Passive infrared sensor (PIR)
Micro SD/SDHC card slot
DC Power Connector
Ethernet Cable Connector
Privacy Button
Reset Button
LEDs
Power/Ethernet states/ Privacy
Power
Output: DC12V / 1 A (Power Adapter)
Power consumption
Max Power Consumption: 6W
Environment
Operating Temperature: 0°C ~ 50°C (32°F ~122°F)
Operating Humidity: 10% ~ 80%
Dimension (L x W x H)
29mm X 60mm X 95mm
Software
Bundled with 32-Channel LevelOne IP CamSecure Lite
surveillance management software
Viewing System Requirement
OS: Microsoft Windows 2000/XP/Vista
Browser: IE 6.x or above
3GPP Player: Real Player 10.5 , Quick Time 6.5 or above
Certication
FCC, CE
Product Diagram
FCS-0030
Remote Viewing via Internet
Modem
Control Console
NAS
Internet/
3G Mobile
Network
Wireless Router
Remote
Viewing
via 3G
Network
FCS-0030
