Hardware Manual
23
Other Adjustments and Accessories
How to Adjust the Viewing Angle and Focus
This section describes the procedures in adjusting the viewing angle and focus of the camera.
The camera already comes pre-focused when you take it out the box. In case there is a need to
modify the default focus and viewing angle, do the procedures below to make the necessary
adjustments.
FCS-1153
Turn the lens knob left or right to adjust the focus.
FCS-1152
The camera comes with the focus and viewing angle already fixed. If necessary, do the following
to modify the focus and viewing angle.
1. Loosen the zoom lever screw, then turn left or right to adjust the viewing angle.
2. Loosen the focus lever screw, then turn left or right to adjust the focus.
