LevelOne FVT-2001 - Gigabit Ethernet Module Specs

11
Gigabit Ethernet Module
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE 802.3ab 1000BaseT
IEEE 802.3z 1000BaseSX/LX standards
IEEE802.3x Flow Control and Back pressure
Connector
Fiber: SC / SFP
RJ-45 Socket: CAT-5 (10/100/1000 Mbps or pure 1000Mbps)
Twisted Pair cable, Auto MDI/MDI-X, Auto-Negotiation
Switch
architecture
Store and Forward
Fiber
parameters
Fiber Core: Multi-Mode (62.5/125um, 50/125um)
Wavelength: 850nm(Multi-mode)
1310nm(Single-mode)
Fiber Distance: 550M (Multi-Mode Fiber)
Transparent
packet
64 to 9000 Bytes for Ethernet packet
Link Lost
Forward
UTP è Fiber: If UTP port link down, then converter will forced
fiber to link down.
Fiber è UTP: If Fiber port link down, the media converter will
force UTP port to link down.
DIP Switch
DIP Switch 1: LFP function
DIP Switch 2: Flow-Control function
LED
Power, UTP (L/A, 100Mbps, 1000Mbps, FDX)
Fiber (L/A)
Power
DC5V, 2A
Dimension
71mm x 94mm x 26mm
EMI & safety
CE, FCC Class A
