LevelOne FVT-2001 - Technical Specifications

10
4. Specification
Fast Ethernet Module
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX/100BASE-FX
IEEE802.3x Flow Control and Back pressure
Connector
Fiber: Duplex ST/SC
RJ-45 Socket: CAT-3/5 (10/100Mbps)
Twisted Pair cable, Auto MDI/MDI-X, Auto-Negotiation
Switch
architecture
Store and Forward
Fiber
parameters
Fiber Core: Multi-Mode (62.5/125um, 50/125um)
Single-Mode (8/125um, 9/125um)
Wavelength: 1310nm(Multi-mode)
1310nm(Single-mode)
1310/1550nm(Single-mode fiber)
Fiber Distance: Multi-Mode Fiber 2KM
Single-Mode Fiber (20KM or 40KM)
Transparent
packet
64 to 1600 Bytes for Non-VLAN Ethernet packet
Link Fault
Pass
through
UTP è Fiber: If UTP port link down, then converter will forced
fiber to link down.
Fiber è UTP: If Fiber port link down, the media converter will
force UTP port to link down.
DIP Switch
DIP Switch 1: LFP function
DIP Switch 2: Flow-Control function
LED
Power, UTP (100Mbps, L/A, FDX)
Fiber (L/A, 100Mbps)
Power
DC5V, 1A
Dimension
71mm x 94mm x 26mm
EMI & safety
CE, FCC Class A
