LevelOne GSW-0507 - LED Definition; GSW-0507 Front Panel; GSW-0807 Front Panel; Rear Panel

LED Definition
GSW-0507 Front Panel
GSW-0807 Front Panel
PWR
On Power is on.
Off Power is off.
Link/Act
(1~5/1~8)
On
One LED indicator will light green when a
device is connected to the corresponding port.
Blinking The port is transmitting/receiving data.
Rear Panel
The rear panel of the GSW-0507/GSW-0807 switch consists
of a DC power connector and 5/8 10/100/1000Mbps RJ45
Ports. The following figure shows the rear panel of the Switch.
y GSW-0507
y GSW-0807
