LevelOne IGC-0101 User Manual

4
Specification
IEEE Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3z 1000Base-X Gigabit Ethernet
IEEE802.3x Flow Control and Back Pressure,
IEEE802.3af for POE
IEEE802.3at for POE+
Switch Architecture
Back-plane (Switching Fabric): 4Gbps
Data Processing
Store and Forward
Flow Control
IEEE 802.3x Flow Control and Back Pressure
Jumbo Frame
9KB
MAC address Table Size
2K
Packet Buffer Size
1M
Network Connector
1 x RJ-45 10/100/1000BaseT(X) PSE with POE
Output power up to 30Watts
1 x 100/1000M SFP
Network Cable
UTP/STP Cat.5e or above Cable
EIA/TIA-568 10-ohm (100m)
Fiber Cable (Multi-mode):50/125um,62.5/125um
Fiber Cable (Single-mode): 9/125um
Protocol
CSMA/CD
LED
PWR (Green): ON－Power is detected
OFF－Power is not detected
SFP Lnk/Act (Green): ON－FX port is detected
Flashing－FX data is transmitting/receiving
RJ-45 port:
Lnk/Act (Green): ON－TX port is detected
Flashing－TX data is transmitting
PoE (Amber): ON－PSE is activated and PD is detected
Flashing－PSE is detecting PD
POE Pin Assignment
30 watts 2 pairs
V-, V-, V+, V+ for pin 1, 2, 3, 6
DIP Switch
DIP 1: Reserved
DIP 2: ON－SFP port 100M
OFF－SFP port 1000M (Default)
Reverse polarity protection
Present
Overload current protection
Present
Power Supply
4 pin terminal block with 48V-56V VDC Power Input,
RLY (Relay): Relay switch for alarm
