4 Specification
Powerline Standards HomePlug AV
PHY Rate Up to 200 Mbps
Modulation 1024/256/64/16/8 QAM, QPSK, BPSK, ROBO Carrier Modulation
Forward Error Correction Turbo Codes
Protocol TDMA, CSMA/CA
Security 128-bit AES Encryption
LEDs
1 * Power
1 * HomePlug
1 * Ethernet
1* 802.3af PoE Ethernet Port
Ethernet Interface 4 * RJ45 LAN Port
Auto-negotiation, Auto MDI/MDIX
Ethernet Standards Ethernet specification IEEE802.3, IEEE802.3u, IEEE802.3af
Power 100 - 240VAC, 50/60 Hz
Power Consumption 100mA (max.)
Operating Temperature
0° C to 40° C
Storage Temperature
-20° C to 70° C
Operating Humidity 10-90%RH (max)
Hardware Operating Sys-
tems
Windows Vista, Windows 2000, Windows XP, Linux, Mac OS X or any other
operating system with network support
