Please remember to press the modify button to take it effect. For store back to
flash memory, please press Save Modification (/System Maintenance/Save
Modification/).
Here is VoIP Routing Profile setting examples below:
Index
Name
VAD
CODEC
H.245
Tunneling
DTMF
Relay
T.38
FAX Relay
Package
Frame
Q.931
Fast
Start
ID1
AS ID2 AS ID3 AS ID4 AS Delete
1 PF1 ON G.723.1 ON Out band ON 3 ON
00001
H.323
1001 E.164 77H77H77HDelete
2 PF2 ON G.723.1 ON In band ON 2 OFF
00002
H.323
1002 E.164 **** Password
78H78H78HDelete
When using profile PF1 , the parameters will be used for H.323 ID1 = 0001,
E.164 ID=1001, DTMF Relay=Out band, Q.931 Fast Start=ON) to call / answer
the VoIP.
When using profile PF2 , the parameters will be used for H.323 ID1 = 0002,
E.164 ID=1002, DTMF Relay=In band, Q.931 Fast Start=OFF, Password=1234
but be hidden ) to call / answer the VoIP.
