-3-
The LAN port is used to connect to network
devices, such as a switch or PC / NB
The WAN/POE port is used to connect to
network devices, such as a POE switch
OR POE adapter to power the device
( IEEE802.3af ) 48 VDC. (POE adapter
unit is to be ordered separately)
Hardware Installation
Power on the Device.
l Plug one end of your Ethernet cable into the WAN port of the AP, and the other end
into a port on a PoE switch or a 802.3af PoE adapter.
Configuring the Device
To set up and manage the AP, you can use one of the following methods:
l Connect the access point and your computer to the same PoE switch. Manage the
access point from the computer. (Figure 1)
Software Installation
To logi n to the LevelOne AP, please perform the following steps:
1. Check Your Network Settings to login web UI.
Please make sure your PC can get IP address automatically, so the router can
communicate with your PC during configuration.
