MIDI
MIDI Show Control
Format:
<sys ex = F0H><real time = 7FH><dev ID><msc = 02><lighing = 01 ><command><data><end sys ex = F7H>
Receives:
Command:
1: Go - Starts current step of active stack or loads stack and step indicated in the data field and executes.
Data (optional):
nn ... nn Cue (step) number, ASCII encoded. 1 - 255 are the only valid numbers.
Any characters after a decimal point will be ignored.
00: Delimiter.
ll ... ll Cue list (Stack numbers), ASCII encoded. 1 - 16 are the only valid
numbers.
Any characters after a decimal point will be ignored.
Ex. Start Step 2 of Stack 4:
F0H 7FH <ID> 02 01 <01> <32H 00 34H> F7H
6: Set
Data: nn nn Control Number, 7-bit, LSB first
vv vv Control Value, 7-bit, LSB first
Control: 0 -31 = Fading Memories 1 - 32
Value: 0 - 255
Values above 255 ignored.
Ex. Memory 2 at full (255):
F0H 7FH <ID> 02 01 <06><01 00 7FH 01>F7H
Control: 32 - 63 = Memories Bumps 1 - 32
Value: 0 - 255
Values above 255 ignored.
Control: 1024 = Memory Page.
Value: 0 - 15
Values above 15 ignored.
Control: 512 - 631 = Channels 1 - 64
Value: 0 - 255
Values above 255 ignored.
Control: 1026 = Activate Chase
Value: 0 - 32, 0 = Chase off, 1 - 32 = Chase 1 - 32
Values above 32 ignored.
Control: 1027 = Chase Rate
Value: 150 - 16383, BPM = (1 / (0.0005 X Value)) X 60
Values below 150 ignored.
