Project Name
Occupancy Sensor Layout
List of Materials
MODEL No. QTY DESCRIPTION MODEL No. QTY DESCRIPTION
ODC0S-I 0 CEILING MOUNTED SELF POWERED PIR 530 SQ FT
OSC04-I0W 0 CEILING MOUNTED PIR, 450 SQ FT
OSC05-M0W 58 CEILING MOUNTED MULTI-TECHNOLOGY, 500 SQ FT
OSC05-U0W 0 CEILING MOUNTED ULTRASONIC, 500 SQ FT
OSC10-M0W 0 CEILING MOUNTED MULTI-TECHNOLOGY, 1000 SQ FT
OSC10-U0W 4 CEILING MOUNTED ULTRASONIC, 1000 SQ FT
OSC15-I0W 30 CEILING MOUNTED PIR, 1500 SQ FT
OSC20-M0W 47 CEILING MOUNTED MULTI-TECHNOLOGY, 2000 SQ FT
OSC20-U0W 0 CEILING MOUNTED ULTRASONIC, 2000 SQ FT
ODS0D-ID 0 WALL SWITCH, DUAL, PIR WITH ADAPTABILITY
ODS10-ID 0 WALL SWITCH PIR
ODS15-ID 0 WALL SWITCH PIR WITH ADAPTABILITY
OSS10-ID 0 WALL SWITCH PIR MANUAL ON AUTO OFF
OSSMT-MD 0 WALL SWITCH MULTI-TECHNOLOGY WITH ADAPTABILITY
OSSMD-MDW 0 WALL SWITCH, DUAL, MULTI-TECH WITH ADAPTABILITY
OSSNL-ID 0 WALL SWITCH PIR WITH ADJUSTABLE NIGHT LIGHT
OSW12-M0W 0 WALL MOUNTED MULTI-TECHNOLOGY
OSWHB-I0W 0 WALL MOUNTED HIGH BAY AISLE PIR
OSWLR-I0W 0 WALL MOUNTED LONG RANGE AISLE PIR
OSWWV-I0W 0 WALL MOUNTED WIDE VIEW PIR MZGen 0 MINIZ GENERIC. CIRCUITING INFORMATION NOT AVAILABLE.
OSFHB-ITW 0 HIGH-BAY FIXTURE MOUNT PIR (360 DEGREES) MZB00-102 0 MINIZ BASIC, 2 RELAY, 120V – 277V
OSFHU 0 HIGH-BAY FIXTURE MOUNT PIR (360 DEGREES OR AISLE) MZB02-102 0 MINIZ BASIC, DUAL ROOM, 2 RELAY, 120V – 277V
OSF10-IDW 0 INTEGRAL FIXTURE OCC SENSOR, 450 SQ FT, 10-120FC PC MZD20-102 0 MINIZ 2 RELAY 2- 0-10V DIMMING, 120V – 277V
PS110-10W 0 OUTDOOR SELF POWERED PIR MZD22-102 0 MINIZ DUAL ROOM, 2 RELAY, 0-10V DIMMING,120V – 277V
PS200-10W 0 OUTDOOR SELF POWERED PIR MZD30-101 0 MINIZ 1-CIRCUIT 3- 0-10V DIMMING, 120V – 277V
OPB15-00W 0 POWER BASE FOR LV CEILING SENSORS MZN20-102 0 MINIZ 2 RELAY 2- 0-10V DIMMING, 120V – 277V
OSP20-0D0 102 POWER PACK FOR 120/230/277VAC SYSTEM MZN22-102 0 MINIZ DUAL ROOM, 2 RELAY, 0-10V DIMMING, 120V – 277V
OSP20-RD0 0 POWER PACK FOR 120/230/277VAC SYSTEM WITH RELAY MZN30-101 0 MINIZ 1-CIRCUIT 3- 0-10V DIMMING, 120V – 277V
OSA20-R00 0 ADD-A-RELAY MZB00-C02 0 MINIZ BASIC, 2 RELAY, 347V
OSP15-R30 0 POWER PACK FOR 347VAC SYSTEM WITH RELAY MZB02-C02 0 MINIZ BASIC, DUAL ROOM, 2 RELAY, 347V
ODC0P-W 0 PHOTO CELL, CEILING MOUNT MZD20-C02 0 MINIZ 2 RELAY 2- 0-10V DIMMING, 347V
PCIND 0 PHOTO CELL, INDOOR, 6-50FC MZD22-C02 0 MINIZ DUAL ROOM, 2 RELAY, 0-10V DIMMING, 347V
PCOUT 0 PHOTO CELL, OUTDOOR, 5-750FC MZD30-C01 0 MINIZ 1-CIRCUIT 3- 0-10V DIMMING, 347V
PCATR 0 PHOTO CELL, ATRIUM, 200-2500FC MZN20-C02 0 MINIZ 2 RELAY 2- 0-10V DIMMING, 347V
PCSKY 0 PHOTO CELL, SKY, 10-7500FC MZN22-C02 0 MINIZ DUAL ROOM, 2 RELAY, 0-10V DIMMING, 347V
WSS04-I0W 0 WIRELESS SESOR, SELF POWERED PIR SENSOR, 450 SQ FT MZN30-C01 0 MINIZ 1-CIRCUIT 3- 0-10V DIMMING, 347V
WSS15-I0W 0 WIRELESS SESOR, SELF POWERED PIR SENSOR, 1500 SQ FT LV200-00W 0 DIMMING CONTROLLER 5 BUTTON
WSS10-0D 0 WIRELESS SENSOR RECEIVER SWITCH, WITH NEUTRAL LV221-00W 0 DIMMING CONTROLLER
WSS10-GD 0 WIRELESS SENSOR RECEIVER SWITCH, NO NEUTRAL LV230-00W 0 SLIDER DIMMING CONTROLLER
WSS0S-P0 0 WIRELESS SENSOR SELF POWERED REMOTE SWITCH LV240-00W 0 SWITCHING CONTROLLER ON/OFF
241 TOTAL SENSORS 0 TOTAL DAYLIGHT
241 DEVICE TOTAL
Project Number - OS#
April 27, 2009
Device Totals
PL-AE-F0XX Rev.1 03-19-07
Page 1 of 1
