Leviton OSFHU - Page 3

OSFHU
OSFOA
50/60H
240/480
Line
240/480V
50/60 HZ
Hot (Black)
Hot (Black)
Black
Black
Sensor
Red
Red
Load
OSFHU (480V) Wiring Diagram
Hot (Black)
Red
Black
White
White
Sensor
Load
Black
Neutral (White)
Line
120-277-347 V
AC
50/60Hz
OSFHU Wiring Diagram
0.75”
(19.05mm)
0.87”
(22.09mm)
Sheet Metal* Punch Dimensions
for Optional Snap-In Installation
*18-22 Gauge Steel
Leviton Manufacturing Co., Inc. Global Headquarters
201 North Service Road, Melville, NY 11747-3138 tech line 800-824-3005 fax 800-832-9538
©2017 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.
INSTALLATION
