Leviton QuickPort Duplex 106 User Manual

Front View Side View
1.5"
1.75"
4.1"
1.2"
Front View Side View
1.3"
1.4" 1.2”
.45"
4.1"
G-6057/C1-5M/jc
© 2001 Leviton Manufacturing Co., Inc. All Rights Reserved
QuickPort
®
Field-Configurable
Connector Housings
Part Numbers
41087-xxP
2222 – 222nd St. SE • Bothell, WA 98021 USA • Tel: 1-800-722-2082 / 1-425-485-4288 • Fax: 1-425-483-5270 • Int'l Fax: 1-425-485-9170 • GSA# GS-35F-4785G
For Applications Engineering Support – Call 1-425-485-4288; in USA call 1-800-722-2082.
Spec sheets and updates are also available at www.levitonvoicedata.com.
DIMENSIONAL LINE ART
See ELECTRONIC FILES for CAD images
(.DXF, .DWG, MS-DOS.EPS)
PART NUMBER
41087-Q*P
41087-2*P
41070-*
Quad 106
Duplex 106
TR Plus
QuickPort 12-Port Surface Mount Housing
Part No.
Note: QuickPort
®
snap-in modules (jacks and bulkhead connectors and cou-
plings), Decora
®
wallplates and Decora Plus
®
wallplates are sold separately.
Please refer to the QuickPort ® module spec sheets and the Leviton catalog
for ordering information.
Available in these colors:
Ivory (I), White (W), Grey (G), Black (E).
* = color
QuickPort
®
Quad 106
Flush Mount Jack
QuickPort
®
Duplex
Flush Mount Jack

Leviton QuickPort Duplex 106 Specifications

General

Brand	Leviton
Model	QuickPort Duplex 106
Category	Cables and connectors
Language	English
