3
TURBO CONNECT UNIT (TCU)
Fig. 2.2
Some Levo models are equipped with the
TCU 1 display. The display turns on the motor,
and provides access to the support modes
options, battery charge level and error codes.
TURBO CONNECT UNIT 2 (TCU 2)
Fig. 2.3
Other Levo models are equipped with the TCU
2 display. The display turns on the motor, and
provides a visual on the display for Speed,
Battery charge level, Mode, Heart Rate, Error
Codes, Distance Ridden, Elevation, Rider
Power, Odometer, Time Ridden, and Time
of Day.
3. GEOMETRY
B
A
C
D
O
E
F
G
H
I
J
K
L
M
N
2.2
2.3
