Levoit VortexIQ 40 User Manual

12
When dust in the dust bin reaches the MAX
line, empty the dust bin.
1. Turn the vacuum o. Remove the
vacuum body by pressing the
Vacuum Body Release Button.
2. Hold the dust bin over a trash can
and press the Dust Bin Release
Button [Figure 2.8]. Use caution,
as the door will automatically open
when the release button is pushed.
3. Empty out debris and dirt, then close
the door.
CARE & MAINTENANCE (CONT.)
Battery Indicator Light Chart
(While Charging)
Emptying the Dust Bin
Battery Level Battery Indicator
0–30% 3 flashing lights
30–60%
1 solid light &
2 flashing lights
60–85%
2 solid lights &
1 flashing light
85–100% 3 solid lights
Figure 2.8
Warning:
• Only charge the battery with the charger
specified by Arovast Corporation.
• If you are not using the battery for an
extended period, store it in a cool, dry place.
• Store the battery in a semi-charged state
(at least half charged) and maintain this by
charging the battery every 3 months.
• If you need an additional battery, contact
Customer Support (see page 19).

Levoit VortexIQ 40 Specifications

General

Brush shape	Rectangular
Product type	Stick vacuum
Dust capacity	0.6 L
Product color	Gray
Dust container type	Bagless
Removable handheld vacuum	Yes
Cleaning type	Dry
Vacuum air filtering	HEPA
Dirt separating method	Cyclonic
Air filtration stages quantity	4
Motor power	400 W
Power source	Battery
Charging time	5 h
Suction power	130 AW
Battery voltage	25.9 V
AC input voltage	100 - 240 V
Battery capacity	2500 Ah
AC input frequency	50 - 60 Hz
Maximum input power	- W
Vacuum brushes included	Dusting brush

Weight and Dimensions

Depth	230 mm
Width	250 mm
Height	1170 mm
Weight	3200 g
