Lewmar EVO 45 - Hydraulic Performance Graphs

20
(C) Line Speed
(A) Load
(m/min)
(B) Pressure (D) Flow
(l/min)
(gal/min)
(bar)
(psi)
(/min)
(kg)(lbs)
(C) Line Speed
(A) Load
(m/min)
(B) Pressure (D) Flow
(l/min)
(gal/min)
(bar)
(psi)
(ft/min)
(kg)(lbs)
(C) Line Speed
(A) Load
(m/min)
(B) Pressure (D) Flow
(l/min)
(gal/min)
(bar)
(psi)
(ft/min)
(kg)(lbs)
OCEAN 46 + EVO® 45
OCEAN 48 + EVO® 50
OCEAN 50
GB
6.4 Hydraulic performance
The following graphs show line speed and load characteristics against hydraulic flow and pressure. The following
graphs show the maximum performance envelope. Refer to trouble shooting (section 9) if performance is inferior.
(A) Load / (B) Pressure / (C) Line Speed / (D) Flow
• Safe Working Loads (SWL) for hydraulic winches are lower than hand controlled winches due to
significantly higher input/torque.
• If winch models 68-111 are installed with an Autoshi Commander unit, only one deck switch may be
required. Winch models 46-64 + EVO® 45-65 are single switch operation only. Refer to Commander manual
for deck switch installation details.
