DRIVE DIMENSIONS —
FIGURE 2
A. 2 Holes Helicoiled M10
(Thru' hole optional)
ABMESSUNGEN DES ANTRIEBS —
ABBILDUNG 2
A. 2 m10-gewindebohrungen
(durchgangsloch wahlweise)
DIMENSIONES DEL ACTUADOR —
FIGURA 2
A. 2 orificios dotados de helicoils de M10
(opcionalmente orificios pasantes)
DIMENSIONS DE L’UNITÉ —
FIGURE 2
A. 2 trous hélicoïdes m10
(trous traversiers en option)
DRIVSYSTEMETS MÅTT —
FIGURE 2
A. 2 hål skruvformiga m10
(genom hål valfritt)
SN155/255 - 256mm
SN355 - 277mm
SN155/255 - 188mm
SN355 - 210mm
55mm
163mm
