MC-8 Appendix
A-3
Specifications are subject to change without notice.
Microphone Input Connectors
Inputs • 4 3.5mm miniature phone jacks
Input Sensitivity • 10mV Rms (400mV maximum input level)
Input Impedance • 20kΩ (accepts balanced or unbalanced input signals)
Other
Trigger Outputs • One power on/off and one programmable connector on
detachable screw terminals (+12 VDC, 0.5 amps each)
RS-232 Serial Input/
Output
• Two 9-pin D-sub connectors
Power Requirements • 90-250 VAC, 50-60Hz, 60W (universal line input), detach-
able power cord
MC-8
Dimensions &
Weight
• Height (with feet): 3.81 inches (97mm)
• Width: 17.3 inches (440mm)
• Depth: 14.85 inches (377mm)
• Weight: 17 lb (7.6kg)
MC-8 Balanced
Dimensions &
Weight
• Height (with feet): 5.04 inches (128mm)
• Width: 17.3 inches (440mm)
• Depth: 14.85 inches (377mm)
• Weight: 24 lb (10.7kg)
Rack-Mounting • Optional brackets are available for installation in a stan-
dard 19" equipment rack (two rack units required for
MC-8; three rack units required for MC-8 Balanced)
Environment • Operating temperature: 0° to 35°C (32° to 95°F)
• Storage temperature: –30° to 75°C (–22° to 167°F)
• Relative humidity: 95% maximum without condensation
Remote Control • Handheld, backlit infrared remote control unit
• Requires 2 AA batteries (alkaline batteries recommended)
Video Input & Output Connectors
Video Inputs • Five composite (RCA), five S-Video and three component
video (RCA)
Video Outputs • Two composite (RCA, one monitor and one Zone 2), two
S-Video (one monitor and one Zone 2) and one compo-
nent (RCA)
Composite & S-Video Performance
Compatibility • NTSC, PAL and SECAM
Switching • Active
Output Level • 1.0V peak-to-peak
Impedance
• 75Ω
Input Return Loss • >40dB
Differential Gain • <0.5%
Differential Phase • <0.5°
Bandwidth • >25MHz
K Factor • <0.3%
Gain • ±0.15dB
Signal-to-Noise Ratio • >65dB
Frequency Response • 10Hz to 10MHz + 0.1/–0.3dB
Component Video Performance
Compatibility • 3-Channel (Y, Pr, Pb), format-independent
Switching • Passive
Impedance • 75Ω
Insertion Loss • <3dB
Bandwidth • >150MHz
