Lexicon MC-8 User Manual

Basic Operation Lexicon
2-8
REAR-PANEL OVERVIEW (continued)
The MC-8 is shown on page 2-6. The MC-8 Balanced, shown below, includes balanced analog audio output connectors for the Main Zone and Zone 2.
Otherwise, both models are identical. The numbers in the rear-panel illustrations correspond with the numbered items in the text.
CAUTION! Never make or break connections to the MC-8 unless the MC-8 and all associated components are powered off.
1
7
14
8
11
10
13 12
9
15
2
5
4
3
6
