CONFIGURING ADVANCE INPUT SETTINGS (continued)
S-VIDEO OSD 4:3 ON, OFF
Controls the appearance of the on-screen display when the display
device is connected to an S-Video output connector. When set to
ON, the display device shows the on-screen display in a 4:3 aspect
ratio, regardless of the incoming signal.
When OFF, the display device shows the on-screen display in the
same aspect ratio as the incoming video input signal.
Note:
The on-screen display appears horizontally stretched across the display
device screen when all of the following conditions are present:
• The S-VIDEO OSD 4:3 parameter is OFF.
• An anamorphic video input signal is present.
• A 16:9 display device (widescreen) is connected to an S-Video
output connector.
COMPONENT OSD ON, OFF
Controls the appearance of the on-screen display when the display
device is connected to the component video output connector.
When ON, the display device shows the on-screen display as a 480i
video signal on a full blue-screen background. To minimize viewing
distractions, the two-line status does not appear in the on-screen
display. When OFF, the display device does not show the on-screen
display, including the two-line status.
Note:
When the ON-SCREEN DISPLAY menu BACKGROUND parameter is OFF,
the display device using the component video output connector will not
show the on-screen display.
ZONE2 IN DIGITAL, ANLG, DMIX
Controls the interaction of the digital and analog audio input
connectors assigned to the current Zone 2 inputs. The table on the
next page describes ZONE2 IN parameter settings.
Caution!
When the ZONE2 IN parameter is set to DIGITAL or ANLG,
the MC-8 recognizes some DTS-encoded sources as audio
signals (not data signals) and outputs loud digital noise
from the Zone 2 audio output connectors.
INPUTSSETUP
