Lexicon MC-8 User Manual

Setup Lexicon
3-60
5 ST. & 5.1 ANLG
Configures the analog audio input connectors as five stereo
connectors and one 5.1-channel configuration.
When the analog audio input connectors are configured as five
stereo and one 5.1-channel configuration:
• The connectors labeled 1, 2, 3, 4 and 5 are configured as
stereo connectors.
• The connectors labeled 6, 7 and 8 are configured as a 5.1-channel
connector. This connector is sent to the Main Zone audio output
connectors, as indicated in the table at the bottom of the next
column.
• Two-channel sources that were assigned to the stereo connectors
labeled 6, 7 and 8 are reassigned to the 5.1-channel connector
labeled 5.1 ANLG (6-8). The 5.1-channel connectors should only be
used with 5.1-channel analog sources such as DVD-As and SACDs.
2 ST. & (2) 5.1 ANLG
Configures the analog audio input connectors as two stereo
connectors and two 5.1-channel configurations.
When the analog audio input connectors are configured as two
stereo and two 5.1-channel connectors:
• The connectors labeled 1 and 2 are configured as stereo connectors.
• The connectors labeled 3, 4 and 5 are configured as a 5.1-
channel connector, and the connectors labeled 6, 7 and 8 are
configured as a 5.1-channel connector. These connectors are
sent to the Main Zone audio output connectors as indicated in
the table at the bottom of this column.
• 2-channel sources that were assigned to the stereo connectors
labeled 3, 4 and 5 are reassigned to the 5.1-channel connector
labeled 5.1 ANLG (3-5). Two-channel sources that were assigned
to the stereo connectors labeled 6, 7 and 8 are reassigned to the
5.1-channel connector labeled 5.1 ANLG (6-8). The 5.1-channel
connectors should only be used with 5.1-channel analog
sources such as DVD-As and SACDs.
The 5.1-channel analog audio input connectors are sent to the Main
Zone analog audio output connectors, as shown in the table below.
REAR PANEL CONFIGSETUP 5 ST. & 5.1 ANLG
Input Connector Output Connector
(L) Front L
(R) Front R
(C) Center
(SUB) Subwoofer
(LS) Side L and Rear L
(RS) Side R and Rear R
REAR PANEL CONFIGSETUP 2 ST. & (2) 5.1 ANLG
