CASCADE STEREO
The left and right signals are processed together in one
virtual machine, and the resulting signal is sent to a second
virtual machine, where they are again processed together.
DUAL MONO
The left signal travels through one virtual machine, and
the right signal travels through a separate second virtual
machine.
QUAD MONO
Four mono signals are processed independently by four vir-
tual machines.
CASCADE MONO
The left signal is sent through two virtual machines in
sequence, while the right signal is sent through two addi-
tional virtual machines in sequence. The left and right sig-
nals are processed independent from each other.
DUAL MONO + SINGLE STEREO
Two mono signals are processed independently by two vir-
tual machines, while a stereo signal is processed by a third
virtual machine.
CASCADE MONO TO STEREO
The left and right signals are processed independently in
two separate virtual machines, and their resulting signals
are processed together in a third virtual machine. The final
result is output as stereo.
SINGLE TWO IN FOUR OUT
Two signals are processed by one virtual machine, and out-
put as four signals.
