Mode Adjust Lexicon
6-26
5.1a BYPASS
• Designed for playback of 5.1-channel analog sources, such as
DVD-A or SACD players.
• Sends the 5.1-channel analog audio input connector directly to
the Main Zone volume control and audio output connectors, as
shown on pages 2-9 and 3-59. These signals receive no internal
processing.
• When both side and rear speakers are present, surround
channel signals are sent in parallel to the side and rear speakers.
To configure a 5-channel speaker setup, set the OUTPUT
LEVELS menu SIDE L/R or REAR L/R parameter to OFF to
deactivate the associated surround speakers.
• Pressing the remote control HOME/MAIN/AGE2/A BYP then
2CH buttons toggles the MAIN ADV menu ANALOG BYPASS
parameter between ON and OFF.
Note:
Speaker crossover settings, speaker distances and audio (tone) controls
are not available when the 5.1a BYPASS listening mode is activated.
2CH BYPASS
This listening mode sends 2-channel analog audio input signals to
the Main Zone audio output connectors labeled Front L/R with no
internal processing.
The 2CH BYPASS listening mode is automatically activated
whenever a 2-channel analog source is present and the MAIN ADV
menu ANALOG BYPASS parameter is set to ON. The 2CH BYPASS
listening mode is not available when a digital source is present and
the MAIN ADV menu INPUT SELECT parameter is set to AUTO.
Pressing the remote control HOME/MAIN/PAGE2/A BYP button then
2CH buttons toggles the MAIN ADV menu ANALOG BYPASS
parameter between ON and OFF.
Note:
Speaker crossover settings, speaker distances and audio controls (tone) are
not available when the 2CH BYPASS listening mode is activated.
Parameter Default Setting Possible Settings
OUTPUT LEVELS Refer to page 6-28
CUSTOM Refer to page 6-28
MODE ADJUST 5.1a BYPASS
MODE ADJUST 2CH BYPASS
To Next Page
