Lexmark C540N Service Manual

Diagnostic aids 3-33
5025-2xx, 4xx
Go Back
Previous
Next
200 paper jams
1.
Remove the standard 250-sheet tray (tray 1).
2. Remove the jam.
Note: Make sure all paper fragments are removed.
3. Insert the tray.
4. Press Select ().
201 paper jam
1.
Grasp the front door at the side handholds, and then pull it toward you to open it.
2. Remove the jammed paper.
Note: Make sure all paper fragments are removed.
3. Close the top door.
4. Press Select ().

Lexmark C540N Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	250 sheets
Input Capacity	250 sheets
Output Trays Capacity	150 sheets
Connectivity	USB, Ethernet
Processor	400 MHz
Standard Memory	128 MB
Network Ready	Yes
Warranty	1 Year
Printer Type	Laser
Recommended Monthly Volume	1500 - 3000 pages
Operating System Compatibility	Windows, Mac, Linux
Media Type	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Network	10/100 Base-TX Ethernet
