Connecting using an Ethernet network
Wired setup and connection
1 Connect the Ethernet cable to the printer and to an active Ethernet port on the network.
Make sure the computer you are using to configure the printer is attached to a working network port on the same
network as the printer.
2 Connect the power cable to the printer and then to a properly grounded electrical outlet, and then turn the printer
on.
3 Insert the Software and Documentation CD.
4 Click Install.
5 Click Agree.
6 Click Suggested.
7 Click Wired Network Attach.
8 Follow the on-screen instructions to complete the wired configuration.
Note: For information on telephone and fax setup, see the User's Guide on the Software and Documentation CD.
Connecting using an Ethernet network
33
