Lexmark CS410 Color Quality Guide

Use To
Color Saver
On
Off
Reduce the amount of toner used for graphics and images. The amount of toner used for text
is not reduced.
Notes:
• Off is the factory default setting.
• On overrides Toner Darkness settings.
RGB Brightness
‑6 to 6
Adjust the printed output either by lightening or darkening it. You can conserve toner by
lightening the output.
Note: 0 is the factory default setting.
RGB Contrast
0–5
Adjust the contrast of printed objects.
Note: 0 is the factory default setting.
RGB Saturation
0–5
Adjust saturation in color outputs.
Note: 0 is the factory default setting.
Color Balance
Cyan
‑5 to 5
Magenta
‑5 to 5
Yellow
‑5 to 5
Black
‑5 to 5
Reset Defaults
Adjust color in printed output by increasing or decreasing the amount of toner being used for
each color.
Note: 0 is the factory default setting.
Color Samples
sRGB Display
sRGB Vivid
Display—True Black
Vivid
Off—RGB
US CMYK
Euro CMYK
Vivid CMYK
Off—CMYK
Print sample pages for each of the RGB and CMYK color conversion tables used in the printer.
Notes:
• Selecting any setting prints the sample.
• Color samples consist of a series of colored boxes along with the RGB or CMYK
combination that creates the color observed. These pages can be used to help decide
which combinations to use to get the printed output you want.
• To access a complete list of color sample pages using the Embedded Web Server, type
the network printer IP address in the Web browser address field.
Color quality guide
Page 2 of 6

Lexmark CS410 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB, Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Monthly Duty Cycle	75, 000 pages
Maximum Memory	2304 MB
Duplex Printing	Yes
Mobile Printing	Yes
