Lexmark CS622de - Assembly 4: Paper Path and Frame Parts

Assembly 4: Paper path and frame
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X2305 1 1Fuser deflector
“Exit deflector removal” on page 308
2 41X2349 1 1 Narrow media/bin full
flag
“Narrow media/bin full sensor flag
removal” on page 346
341X2350 1 1Right deflector flag
“Right output bin deflector removal” on
page 348
4 41X1041 1 1 110 V Fuser
“Fuser removal” on page 305
4 41X1300 1 1 220 V Fuser
“Fuser removal” on page 305
4 41X1299 1 1 100 V Fuser
“Fuser removal” on page 305
541X1040 1 1Printhead
“Printhead removal” on page 346
6 40X7629 1 1 Motor (fuser drive)
“Motor (fuser drive) removal” on
page 257
7 41X2327 1 1 Subframe cable cover --
8 41X1312 1 1 Lower right subframe
“Lower right frame removal” on
page 322
940X5168 2 2Pick tires
“Pick tires removal” on page 310
10 41X1292 1 1 Media feeder
“Tray 1 media feeder removal” on
page 333
11 41X1039 1 1 Imaging kit
“Imaging kit removal” on page 273
12 41X0580 1 1 Transfer module guide
“Transfer module guide removal” on
page 329
13 41X2326 1 1 Lower left subframe
“Lower left frame removal” on page
312
14 41X1724 1 1 Drive unit motor kit
“Motor (drive unit) removal” on
page 244
15 41X1289 1 1 EP drive assembly
“EP drive assembly removal” on
page 244
NS 41X2360 4 4 Sub‑frame foot --
5029
Parts catalog
386
