Lexmark CS622de - Assembly 6: Cables and Sensors Parts

Assembly 6: Cables and sensors
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1904 1 1 Sensor (left toner patch with
thermistor)
“Sensors (toner patch)
removal” on page 261
2 41X2348 1 1 Sensor (right toner patch with
thermistor)
“Sensors (toner patch)
removal” on page 261
3 41X1722 1 1 Waste toner bottle contact
block
“Waste toner bottle contact
block removal” on page 277
4 41X1723 4 1 Toner cartridge contact
“Toner cartridge contacts
removal” on page 275
5A 41X2328 1 1 Fuser exit narrow media to
controller board
--
5B 41X2329 1 1 Fuser/input sensor cable --
5C 41X2332 1 1 LVPS to controller board cable --
5D 41X2330 1 1 EP motor to controller board
cable
--
5E 41X2335 1 1 Tray 2 to controller board cable --
5F 41X2334 1 1 HVPS to controller board cable --
5G 41X2336 1 1 Tray present sensor cable --
5H 41X2331 1 1 AC power to LVPS cable --
6 40X7641 1 1 Control panel and USB port
cable pack
--
7 41X1561 1 1 Front and right side interlock
switch cover assembly
“Interlock switch cover
assembly removal” on
page 282
NS 41X2333 1 1 Weather station cable
“Weather station removal” on
page 297
5029
Parts catalog
390
