Assembly 2: 2.4-inch and 4.3-inch control panel
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X2049 1 1 CS421 control panel badge
cover
“2.4‑inch control panel badge
cover removal” on page 286
1 41X2050 1 1 CS521 control panel badge
cover
“2.4‑inch control panel badge
cover removal” on page 286
1 41X2132 1 1 SC2425 control panel
badge cover
“2.4‑inch control panel badge
cover removal” on page 286
1 41X2133 1 1 SC2535 control panel
badge cover
“2.4‑inch control panel badge
cover removal” on page 286
2 41X1304 1 1 2.4-inch control panel bezel
(CS421, C2425, CS521, and
CS2535)
“2.4‑inch control panel bezel
removal” on page 287
3 41X1627 1 1 2.4-inch control panel
assembly (CS421, C2425,
CS521, and CS2535)
“2.4‑inch control panel top cover
removal” on page 292
4 41X1308 1 1 Headphone cable --
541X1309 1 12.4‑inch control panel FFC
(CS421, C2425, CS521, and
CS2535)
“2.4‑inch control panel top cover
removal” on page 292
5 41X2021 1 1 4.3-inch control panel FFC
(CS622 and CS2240)
“4.3‑inch control panel top cover
removal” on page 294
6 41X2021 1 1 Control panel ribbon cable --
741X1307 1 1USB cable
“Front USB cable removal” on
page 301
8 41X1305 1 1 Control panel base cover
“Control panel base removal” on
page 284
9 41X1306 1 1 4.3-inch control panel top
cover (CS622 and CS2240)
“4.3‑inch control panel top cover
removal” on page 294
10 41X2113 1 1 4.3-inch control panel
assembly (CS622 and
CS2240)
“4.3‑inch control panel top cover
removal” on page 294
11 41X1302 1 1 4.3-inch control panel bezel
(CS622 and CS2240)
“4.3‑inch control panel bezel
removal” on page 288
12 41X2115 1 1 4.3-inch control panel
keyboard cover without
volume (CS622 and
CS2240)
“4.3‑inch control panel top cover
removal” on page 294
13 41X1310 1 1 4.3-inch control panel
keyboard cover (CS622
and CS2240)
“4.3‑inch control panel top cover
removal” on page 294
14 41X2048 1 1 CS622 control panel badge
cover
“4.3‑inch control panel badge
cover removal” on page 286
5029
Parts catalog
378
