The following diagrams and tables provide more information about the printer control panel items:
Item Description
1
Menus button ( )
Opens the menus
Note: The menus are available only when the printer is in the Ready state.
2
Back button ( )
Returns the display to the previous screen
3
Stop button ( )
Stops all printer activity
When printing, pressing
causes Stopping to appear momentarily. Then the Stopped screen
appears offering a list of settings that you may select.
4
Indicator light Indicates the printer status:
• Off—The power is off.
• Blinking green—The printer is warming up, processing data, or printing.
• Solid green—The printer is on, but idle.
• Solid red—Operator intervention is needed.
Menu map
