Lexmark Interpret S405 Network Guide

Look for any of these identifier marks to check if your device is WPS certified:
You can find these WPS logos on the side, back, or top of your access point or router.
Configuring the printer wirelessly using WPS (Wi-Fi
Protected Setup)
Wi-Fi Protected Setup (WPS) is a method of configuring computers and printers on a secure wireless network. WPS
is faster than manual configuration, and it reduces typing errors when new devices are added to a wireless network.
The SSID and WPA passphrase are automatically detected and configured for you. The printer supports WPS and can
be configured for wireless access using WPS. In order to use WPS to configure the printer, the wireless router must
also support WPS.
If you want to use WPS to set up your printer, then insert the CD and follow the instructions on the computer screen.
Notes:
• To use WPS to configure the printer wirelessly, all of the devices on your wireless network must support WPS. If
any device on your network does not support WPS, then you must type the SSID and security information when
prompted.
• If you are using the PIN method to add your printer using WPS, make sure you type all eight digits when you are
asked to enter your PIN.
Installing the printer on other computers
Once the printer is set up on the wireless network, it can be accessed wirelessly by any other computer on the network.
However, you will need to install the printer driver on every computer that will access it. You do not need to configure
the printer again, although you will need to run the setup software on each computer to install the driver.
For Windows users
1 Close all open software programs.
2 Insert the installation software CD.
If the Welcome screen does not appear after a minute, then launch the CD manually:
a Click , or click Start and then click Run.
b In the Start Search or Run box, type D:\setup.exe, where D is the letter of your CD or DVD drive.
3 Follow the instructions on the computer screen for installing a configured printer on a new computer.
Wireless networking
5

Lexmark Interpret S405 Specifications

General

Print technology	Inkjet
Resolution color	4800 x 1200 DPI
Maximum resolution	2400 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	17 ppm
Print speed (color, normal quality, A4/US Letter)	11 ppm
Digital sender	No
Printing colors	black, cyan, magenta, yellow
Maximum duty cycle	5000 pages per month
Number of print cartridges	4
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Copy speed (black, normal quality, A4)	15 cpm
Copy speed (color, normal quality, A4)	9 cpm
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Maximum input capacity	100 sheets
Auto document feeder (ADF)	Yes
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	64 MB
Sound pressure level (copying)	47 dB
Sound pressure level (printing)	50 dB
Sound pressure level (scanning)	35 dB
Dimensions (WxDxH)	204 x 338 x 477 mm
Wireless technology	802.11 g/b
All-in-one functions	Copy, Fax, Scan
Standard media sizes	\u003C 216 x 432 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Microsoft Windows 2000 5.00.2195 + / XP / XP Professional x64 / Vista / Vista x64 / 7; Apple Mac OS X 10.4.4-10.6.x Intel / 10.3.9 Power PC / 10.4.4-10.5.x PowerPC; Linux @ www.lexmark.com.
Envelopes sizes	6 3/4, 7 3/4, 9, 10, B5, C5, C6, DL
Paper tray media types	Card stock, Envelopes, Iron-On Transfers, Photo paper, Plain paper, Transparencies
Non-ISO print media sizes	2l, a2 baronial, Executive (184 x 267mm), hagaki card, index card, l, Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Borderless printing media sizes	2L, A4, A5, A6, B5, Hagaki Card, L, Legal, Letter
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR
Certification	CSA, c-UL-us, ICES Class B, Executive Order 132221, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, C-tick mark Class B, V85, CCC Class B, BSMI Class B, METI(PSE), VCCI Class B, FCC Class B, UL 60950 3rd Edition, CCIB
Market positioning	Home & office

Weight and Dimensions

Weight	7760 g
