Lexmark M3150 Connection Guide

In Windows 7 or earlier
a
Click or click Start, and then click Run.
b In the Start Search or Run dialog, type D:\setup.exe.
c Press Enter or click OK.
Note: D is the letter of your CD or DVD drive.
4 Click Install, and then follow the instructions on the computer screen.
5 Select Ethernet connection, and then click Continue.
6 Attach the Ethernet cable to the computer and to the printer when instructed to do so.
7 Select the printer from the list, and then click Continue.
Note: If the configured printer does not appear in the list, then click Modify Search.
8 Follow the instructions on the computer screen.
Sharing the printer on a network
1 Open the printers folder.
In Windows 8
From the Search charm, type run, and then navigate to:
Apps list > Run > type control printers > OK
In Windows 7 or earlier
a
Click or click Start, and then click Run.
b In the Start Search or Run dialog, type control printers.
c Press Enter, or click OK.
2 Depending on your device, do either of the following:
• Press and hold the printer you want to share.
• Right‑click the printer you want to share.
3 From the menu that appears, click Printer Properties or Sharing.
4 From the Sharing tab, select Share this printer or Shared as, and then assign a distinctive name.
5 From the Ports tab, click Add Port > Local Port > New Port.
6 Type the Universal Naming Convention (UNC) port name, and then click OK.
Note: The UNC port name consists of the server name and the distinctive printer name, and should be in the form \
\server\printer.
7 Click Apply > OK.
Connection Guide
Page 4 of 6

Lexmark M3150 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	47 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	3000 - 16000 pages per month
Number of print cartridges	1
Paper input type	Paper tray
Total input capacity	650 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	210 x 297 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	-
Mobile printing technologies	Not supported
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	3
Processor model	2-Core
Processor frequency	800 MHz
Maximum internal memory	2560 MB
Sound pressure level (printing)	55 dB
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Power consumption (printing)	- W
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Depth	396.5 mm
Width	399 mm
Height	306 mm
