Lexmark M5255 - Page 786

Assembly 9: Frames
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1073 2 1 Imaging unit clamp --
2 41X1092 1 1 Rear door right pivot --
3 41X1080 1 1 Inner guide deflector
“Inner guide deflector removal” on
page 438
4 41X1618 1 1 Imaging unit side bias roller --
5 41X1091 3 1 Tray bias roller, front --
5 41X1091 3 1 Tray bias roller, top --
5 41X1091 3 1 Tray bias roller, rear --
