6 Insert the new hot roll fuser until it clicks into place.
7 Lock the hot roll fuser.
8 Close the door.
9 Install the standard bin cover.
Replacing the transfer roller
1 Open door A.
Warning—Potential Damage: To prevent damage from electrostatic discharge, touch any exposed metal
frame of the printer before accessing or touching interior areas of the printer.
Maintaining the printer 113
