Lexmark MS310d Quick Refence Guide

If the supplemental light sequence matches the light sequence in the preceding illustration, then do the following.
CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching it.
1 Press the button on the right side of the printer, and then open the front door.
2
1
2 Pull out the toner cartridge using the handle.
3 Lift the green handle, and then pull out the imaging unit from the printer.
Warning—Potential Damage: Do not touch the photoconductor drum. Doing so may affect the print quality of
future print jobs.
25

Lexmark MS310d Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor Speed	800 MHz
Paper Input Capacity	250 sheets
Operating System Compatibility	Windows, Mac, Linux
Print Resolution (Black)	1200 x 1200 dpi
Connectivity	Ethernet
Media Sizes Supported	A4, A5, A6, Letter, Legal, Executive, B5, Envelopes
Functions	Print
Maximum Paper Size	Legal
