Printer model Height Width Depth Weight with cartridge
and imaging unit
(unpackaged)
MS610de 305.9 mm (12.1 in.) 399 mm (15.7 in.) 396.5 mm (15.6 in.) 16.2 kg (35.7 lb)
MS610dte 414 mm (16.3 in.) 399 mm (15.7 in.) 396.5 mm (15.6 in.) 20.9 kg (46.1 lb)
Multifunction printer dimensions (unpackaged)
Printer model Height Width Depth Weight
(unpackaged, no options)
MX310dn, MX410de 468 mm (18.4 in.) 399 mm (15.7 in.) 472 mm (18.6 in.) 20 kg (44 lb)
MX510de, MX511de, MX511dhe 502 mm (19.8 in.) 489 mm (19.3 in.) 452 mm (17.8 in.) 21.8 kg (48 lb)
MX510dte 610 mm (24.0 in.) 489 mm (19.3 in.) 452 mm (17.8 in.) 26.5 kg (58.4 lb)
MX610de, MX611de, MX611dhe 561 mm (22.1 in.) 489 mm (19.3 in.) 479 mm (18.9 in.) 23.6 kg (52 lb)
MX611dte 669 mm (26.3 in.) 489 mm (19.3 in.) 479 mm (18.9 in.) 28.3 kg (62.4 lb)
Dimensions of the MS310, MS312, MS315, MS410, MS415, MS510, MS610, MX310, MX410, MX51x, MX61x
hardware options
Option Height Width Depth Weight
Footprint 389 mm (15.3 in.) 382 mm (15 in.)
Input options
550‑sheet tray 109 mm (4.3 in.) 389 mm (15.3 in.) 382 mm (15 in.) 4.7 kg (10.4 lb)
250‑sheet tray 77 mm (3 in.) 389 mm (15.3 in.) 382 mm (15 in.) 4.2 kg (9.3 lb)
Furniture options
Adjustable printer stand 584.2 mm (23 in.) 596.9 mm (23.5 in.) 596.9 mm (23.5 in.) 25 kg (55 lb)
Swivel cabinet (for
MS310, MS312, MS315,
MS410, MS415, MS510,
MS610 only)
263 mm (10.4 in.) 476 mm (18.7 in.) 600 mm (23.6 in.) 21.8 kg (48 lb)
Output option
Stapler (for MX61x
only)
*
195 mm (7.7 in.) 409 mm (16.1 in.) 371.5 mm (14.6 in.) 24.9 kg (55 lb)
*
Stapler adds 2.5 inches to the depth of the printer.
Clearance requirements
Note: These clearance values are for the most compact operating configuration of the product. Additional clearance
(especially from the front) may be needed to utilize the multipurpose feeder, clear paper misfeed, lift the scanner lid (for
MFPs only), or replace toner and imaging unit.
Clearance requirements for the SFP
Printer model Left side Right side Front Rear Top
MS310, MS312,
MS315, MS410,
MS415, MS510,
MS610
65 mm (2.56 in.) 110 mm (4.33 in.) 305 mm (12 in.) 100 mm (3.94 in.) 305 mm (12 in.)
Printer specifications 18

Lexmark MS310dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Wi-Fi	-
Security algorithms	802.1x RADIUS, LEAP, MD5, PEAP
Mobile printing technologies	Not supported
Supported network protocols (IPv4)	TCP/IP
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 2500 pages per month
Number of print cartridges	1
Internal memory	128 MB
Processor frequency	800 MHz
Sound power level (standby)	15 dB
Sound pressure level (printing)	53 dB
Sound pressure level (quiet mode)	50 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	2
Maximum number of input trays	3
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	80 - 75 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Wireless LAN
Power consumption (standby)	0.5 W
Power consumption (printing)	520 W
Power consumption (PowerSave)	5 W
Package depth	472.4 mm
Package width	431.8 mm
Package weight	15807 g
Sustainability certificates	ENERGY STAR
Certification	CAN/CSA, ICES, BSMI, VCCI, US FDA, FCC, IEC, SEMKO, UL AR, CS, TÜV, CISPIR, ECMA, TED
Product color	Black, White
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Other operating systems supported	IBM iSeries, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	381 mm
Width	398.7 mm
Height	261.6 mm
Weight	14016 g
