= Supported
X = Not supported
Printer model
Command Function
MS310, MS312,
MS315, MS410,
MS415, MS510,
MS610
MX310, MX410,
MX510, MX511
MX610, MX611
ESC
&l#P
Set Page Length
ESC
&l#S
Simplex/Duplex
ESC
&l1T
Job Separation XXX
ESC
&l#U
Left (Long-Edge) Offset
Registration
ESC
&l#X
Set Copy Count
ESC
&l#Z
Top (Short-Edge) Offset
Registration
ESC
&n#W [operation] [string id]
Alphanumeric ID
ESC
&p#C
Palette Control
ESC
&p#I
Palette Control ID
ESC
&p#S
Select Palette
ESC
&p#X[data]
Transparent Print Data
ESC
&r#F
Flush All Pages
ESC
&s#C
End-Of-Line Text Wrap
ESC
&t#P
Text Parsing Method
ESC
&u#D
Unit of Measure
ESC
(#
Select Symbol Set
ESC
(#X
Select Font by ID
ESC
(3@
Select Default Primary Font
ESC
(f#W[data]
Define Symbol Set
ESC
(s#B
Select Stroke Weight
ESC
(s#H
Select Pitch
ESC
(s#P
Select Spacing
ESC
(s#S
Select Style
ESC
(s#T
Select Typeface
ESC
(s#V
Select Point Size
ESC
(s#W[data]
Load Character
ESC
)#
Secondary Font Symbol Set
Appendix A: PCL support 23
