Lexmark MS312dn User Manual

• Make sure a wireless network adapter is installed in your printer and is working properly.
1 From the Finder, navigate to:
Applications > select your printer folder
2 Double‑click Wireless Setup Assistant, and then follow the instructions on the computer screen.
Note: If you encounter problems while running the application, then click
?
.
Connecting the printer to a wireless network using the
Embedded Web Server
Before you begin, make sure that:
• Your printer is connected temporarily to an Ethernet network.
• A wireless network adapter is installed in your printer and working properly. For more information, see the
instruction sheet that came with your wireless network adapter.
1 Open a Web browser, and then type the printer IP address in the address field.
Notes:
• View the printer IP address on the printer control panel. The IP address appears as four sets of
numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Click Settings > Network/Ports > Wireless.
3 Modify the settings to match the settings of your access point (wireless router).
Note: Make sure to enter the correct SSID.
4 Click Submit.
5 Turn
o
the printer, and then disconnect the Ethernet cable. Then wait for at least
five
seconds, and then
turn the printer back on.
6 To verify if your printer is connected to the network, print a network setup page. Then in the Network Card [x]
section, see if the status is Connected.
Verifying printer setup
MS312 and MS317 printing menu settings and network setup pages
Printing a menu settings page
Print a menu settings page to review the current menu settings and to verify if the printer options are installed
correctly.
Additional printer setup 24

Lexmark MS312dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	16 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 2500 pages per month
Number of print cartridges	-
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PostScript 3, PPDS
Paper input type	Paper tray
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 24 lbs
Multi-Purpose Tray media weight (imperial)	16 - 43 lbs
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Mobile printing technologies	Apple AirPrint
Supported network protocols (IPv4)	TCP/IP IPv4 AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6 TCP UDP
Standard interfaces	Ethernet, Parallel, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Internal memory	128 MB
Processor model	2-Core
Noise level (idle)	15 dB
Processor frequency	800 MHz
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Display	LCD
Certification	ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, Customs Union EAC, SII, TER
Product color	Black, White
Display number of lines	2 lines
Power consumption (printing)	520 W
Sustainability certificates	ENERGY STAR
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	472 mm
Package width	432 mm
Package weight	15807 g

Weight and Dimensions

Depth	381 mm
Width	398.7 mm
Height	261.6 mm
Weight	14016 g
