Managing the printer
Finding advanced networking and administrator
information
This chapter covers basic administrative support tasks using the Embedded Web Server. For more advanced
system support tasks, see the Networking Guide on the Software and Documentation CD or the Embedded
Web Server — Security: Administrator's Guide on the Lexmark support Web site at
http://support.lexmark.com.
Copying printer settings to other printers
Note: This feature is available only in network printers.
1 Open a Web browser, and then type the printer IP address in the address field.
Notes:
View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears
as four sets of numbers separated by periods, such as 123.123.123.123.
If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Click the Copy Printer Settings.
3 To change the language, select a language from the drop-down menu, and then click Click here to submit
language.
4 Click Printer Settings.
5 Type the IP addresses of the source and target printers in their appropriate fields.
Note: If you want to add or remove a target printer, then click Add Target IP or Remove Target IP.
6 Click Copy Printer Settings.
Configuring supply notifications from the Embedded Web
Server
You can determine how you would like to be
notified
when supplies run nearly low, low, very low, or reach their
endoflife by setting the selectable alerts.
Notes:
Selectable alerts can be set on the toner cartridge and imaging unit.
All selectable alerts can be set for nearly low, low, and very low supply conditions. Not all selectable
alerts can be set for the endoflife supply condition. Email selectable alert is available for all supply
conditions.
The percentage of estimated remaining supply that prompts the alert can be set on some supplies for
some supply conditions.
1 Open a Web browser, and then type the printer IP address in the address field.
Managing the printer 61

Table of Contents

Other manuals for Lexmark MS312dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark MS312dn and is the answer not in the manual?

Lexmark MS312dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto/Manual
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Duplex print speed (black, normal quality, A4/US Letter)16 ppm
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle500 - 2500 pages per month
Number of print cartridges-
Page description languagesMicrosoft XPS, PCL 5e, PCL 6, PostScript 3, PPDS
Paper input typePaper tray
Total input capacity300 sheets
Total output capacity150 sheets
Maximum input capacity850 sheets
Total number of input trays2
Maximum number of input trays3
Multi-Purpose tray input capacity50 sheets
Envelopes sizes7 3/4, 9, 10, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Paper tray media weight (imperial)16 - 24 lbs
Multi-Purpose Tray media weight (imperial)16 - 43 lbs
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Mobile printing technologiesApple AirPrint
Supported network protocols (IPv4)TCP/IP IPv4 AppleTalk
Supported network protocols (IPv6)TCP/IP IPv6 TCP UDP
Standard interfacesEthernet, Parallel, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantity1
Internal memory128 MB
Processor model2-Core
Noise level (idle)15 dB
Processor frequency800 MHz
Sound pressure level (printing)53 dB
Sound pressure level (duplex printing)52 dB
DisplayLCD
CertificationICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, Customs Union EAC, SII, TER
Product colorBlack, White
Display number of lines2 lines
Power consumption (printing)520 W
Sustainability certificatesENERGY STAR
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Package depth472 mm
Package width432 mm
Package weight15807 g
Weight and Dimensions IconWeight and Dimensions
Depth381 mm
Width398.7 mm
Height261.6 mm
Weight14016 g
