Lexmark MS610de - Page 267

6 Remove the screw (B) from the right front mount, and route the cables through the slot.
B
7 Remove the two screws (C) securing the control panel assembly.
C
8 Route all cables o the printer to completely remove the control panel assembly.
4514-6xx
Parts removal
267
