Lexmark MS610dn Service Manual

Actions Yes No
Step 5
Does the IP address displayed on the network settings page match
the IP address in the port of the drivers using the printer?
Go to step 10. Go to step 6.
Step 6
Does the LAN use DHCP?
Note: A printer should use a static IP address on a network.
Go to step 7. Go to step 9.
Step 7
Are the first two segments of the IP address 169.254
Go to step 8. Go to step 9.
Step 8
POR the printer.
Did this resolve the issue?
The problem is
solved.
Go to step 10.
Step 9
Reset the address on the printer to match the IP address on the
driver.
Did this resolve the issue?
The problem is
solved.
Go to step 10.
Step 10
Have the network administrator verify that the printer and PC’s IP
address have identical subnet addresses.
Are the subnet addresses the same?
Go to step 12. Go to step 11.
Step 11
Using the subnet address supplied by the network administrator,
assign a unique IP address to the printer.
Note: The printer IP address should match the IP address on the
printer driver.
Did this fix the problem?
The problem is
solved.
Go to step 12.
Step 12
Is the device physically connected (Ethernet cable) to the network?
Go to step 13. Go to step 15.
Step 13
Try using a dierent Ethernet cable.
Did this fix the problem?
The problem is
solved.
Go to step 14.
Step 14
Have the network administrator check the network drop for activity.
Is the network drop functioning properly?
Replace the
controller board. See
“Controller board
removals” on
page 247.
Contact the network
administrator.
Step 15
Is the printer on the same wireless network as the other devices?
Go to step 17. Go to step 16.
4514-6xx
Diagnostics and troubleshooting
170
