200 paper jams
200 paper jam messages
Notes:
• Some error messages are applicable only to printer models with a polygon LSU (laser scanning unit).
• If the sixth digit character assigned to the serial number of the printer is in the P–Z range, then the
printer is installed with a polygon LSU (example: 4514 2ZHH 007CR).
Error code Description Action
200.01 Input sensor covered during warm-up sequence. Go to
“Sensor (input) static jam service check”
on page 92.
200.02 Input sensor covered too quickly. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.03 Page did not reach input sensor or was late
reaching input sensor, but was successfully
picked from the source.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.05 Input sensor covered too long. Source = [x]. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.08 Page arrive at input senor at unexpected time. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.09 Printhead did not receive proper motor feedback
to start laser servo.
Go to
“Sensor (input) image jam service check”
on page 94.
200.10 Printhead motor not locked when media reaches
the input sensor.
Go to
“Sensor (input) image jam service check”
on page 94.
200.11 Printhead motor fell out of lock after page reaches
the input sensor.
Go to
“Sensor (input) image jam service check”
on page 94.
Mirror motor got locked, and then lost it again
before the initial lock timeout.
Go to
“Laser scanning unit (LSU) service check”
on page 136.
200.12 Printhead was not ready for media. Go to
“Sensor (input) image jam service check”
on page 94.
200.13 Media at input sensor is not the next media to be
imaged.
Go to
“Sensor (input) image jam service check”
on page 94.
200.14 Media reached the input sensor before EP was
ready.
Go to
“Sensor (input) image jam service check”
on page 94.
200.15 Input sensor covered too long. Source = [x]. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.16 Fuser motor stalled. Go to
“Main drive motor control jam service
check” on page 95.
200.21 No response from paper port driver while waiting
for the source to deactivate the Input Source
Ready flag to indicate it has initiated picking.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.23 Laser servo never started due to potential conflict
with the transfer servo.
Go to
“Sensor (input) image jam service check”
on page 94.
4514-6xx
Diagnostics and troubleshooting
90
