200.05 Paper Jam
• This jam means the input sensor did not detect the trailing edge of the
media – usually because multiple sheets were picked.
• Most jams occur under the Imaging Unit, but can occur in the Fuser.
• Multiple sheets can be picked if the media is difficult to separate or the
separator rolls are worn or dirty.
• Ensure the media is supported and stored properly when not loaded
inside the printer trays.
• Media should be loaded properly:
– Fan the media
– Flip the media
– Adjust the tray insert side restraints before loading.
• If the issue persists, replace the separator roll assembly.
• See the pictures on the following page.
Continued on next page...
