Page #52 background imageLoading...
Page #52 background image
Print material
Range or maximum weight supported
500sheet tray and optional
500sheet drawer
Multipurpose feeder
Integrated forms
Pressuresensitive area
4
140–175 g/m
2
140–175 g/m
2
Paper base (grain long)
75–135 g/m
2
(20–36 lb bond)
75–135 g/m
2
(20–36 lb bond)
1
Paper less than 75 g/m
2
is supported only when the relative humidity is less than 60% and is not supported in duplex.
2
See “Grain orientation” on page 17 for specific recommendations.
3
Vinyl labels are supported only when printing environment and media are 20–32°C (68–90°F).
4
Pressuresensitive area must enter the printer first.
For paper and transparency specifications, see the printer publications CD.
The following table indicates the paper sizes each tray supports.
Media specifications
Labels Thickness: 0.102–0.305 mm (0.004–0.012 in.)
Smoothness: 50–300 Sheffield*
* 50–150 Sheffield is optimal. This printer may support labels with smoothness of less than 50 Sheffield such as coated paper,
polyester, vinyl, or other synthetic facestock papers.Using media higher than 200 Sheffield could result in printing
degradation.
Card stock and label guidelines
Labels are one of the most difficult print materials for laser printers. A fuser equipped with a web oiler may be required
for label applications to optimize feed reliability. Contact your local service representative for ordering information.
If you print large quantities of labels or other glossy print media, replace the fuser housing with a web oiler (P/N 56P1555
for a 115 V printer or P/N 56P1556 for a 220 V printer).
When printing on labels:
Using the printer operator panel, set Paper Type to Labels in the Paper Menu. For vinyl and other heavy labels, set
Labels Weight (under the Paper Weight menu) to Heavy, and set Labels Texture (under the Paper Texture menu)
to Smooth.
Do not load labels together with paper or transparencies in the same paper tray. Combining print materials can
cause feeding problems.
Use full label sheets. Partial sheets may cause labels to peel off during printing, resulting in a paper jam. Adhesive
material may contaminate your printer. It could also void your printer and cartridge warranties.
Print on sheets with more number of labels to improve registration.
When printing on card stock:
Set Paper Type to Card Stock in the Paper Menu.
Do not use creased card stock. It may cause paper jams.
For more information, see the following:
“Pick roller technology” on page 11
“Grain orientation” on page 17
Printer specifications 52

Table of Contents

Other manuals for Lexmark MX310dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark MX310dn and is the answer not in the manual?

Lexmark MX310dn Specifications

General IconGeneral
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)33 ppm
Duplex print speed (black, normal quality, A4/US Letter)14 ppm
Finishing optionNo
All-in-one functionsCopy, Fax, Print, Scan
Supported media weight(s)60 - 90 g/m²
Color all-in-one functionsScan
Package dimensions (W x D x H)19.09 x 21.65 x 22.48 \
Supported media weight (imperial)24 lbs
Country of originChina
Maximum duty cycle50000 pages per month
Recommended duty cycle250 - 6000 pages per month
Page description languagesMicrosoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS
Copier resize25 - 400 %
Copy speed (black, normal quality, A4)33 cpm
Scanner typeFlatbed & ADF scanner
Maximum scan area216 x 356 mm
Duplex scan speed (black)43 ppm
Duplex scan speed (color)20 ppm
Optical scanning resolution600 x 1200 DPI
FaxingMono faxing
Modem speed33.6 Kbit/s
Fax transmission speed3 sec/page
Total input capacity300 sheets
Total output capacity150 sheets
Maximum input capacity850 sheets
Total number of input trays2
Maximum number of input trays3
Auto document feeder (ADF) input capacity50 sheets
Envelopes sizes7 3/4, 9, 10, DL
Maximum print size-
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
DisplayLCD
Display diagonal2.4 \
Market positioningBusiness
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantity1
Supported network protocols (IPv4)TCP/IP, AppleTalk, TCP, UDP
Supported network protocols (IPv6)TCP/IP
Internal memory256 MB
Processor frequency800 MHz
Sound pressure level (copying)54 dB
Sound pressure level (printing)53 dB
Sound pressure level (scanning)55 dB
Sound pressure level (duplex printing)52 dB
Power consumption (average operating)- W
Package depth550 mm
Package width485 mm
Package height571 mm
Package weight22500 g
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Other operating systems supportedNovell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Sustainability certificatesENERGY STAR
CertificationBlue Angel (RAL-UZ-122), CAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 B, BSMI B, CNS 13438, VCCI B, US FDA, FCC B, UL 60950-1, IEC 320-1, EN/IEC 60320-1, CE B, CB IEC 60950-1, EN 62311, EN 60950-1, EN/IEC 61000-3, EN 55022 B, EN 55024, EN/IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, SMA C-tick B, CCC B, CISPIR 22 B, EK Mark, N Mark, ECMA-370, TED
Weight and Dimensions IconWeight and Dimensions
Depth472 mm
Width399 mm
Height468 mm
Weight20000 g
