1
2
3
6
8
7
4
5
Use the To
1 Printer power cord
socket
Connect the printer to a properly grounded electrical outlet.
2 Power switch Turn the printer on or off.
3 Ethernet port Connect the printer to an Ethernet network.
4 EXT port Connect additional devices (telephone or answering machine) to the printer and the
telephone line. Use this port if you do not have a dedicated fax line for the printer and if this
connection method is supported in your country or region.
Note: Remove the plug to access the port.
5 LINE port Connect the printer to an active telephone line through a standard wall jack (RJ‑11), DSL
filter, or VoIP adapter, or any other adapter that allows you to access the telephone line to
send and receive faxes.
6 USB port Attach a supported printer keyboard.
7 USB printer port Connect the printer to a computer.
8 Security slot Attach a lock that will secure the printer in place.
Additional printer setup 51
