3 Remove the rear door. See “Rear door removal” on page 549.
4 Remove the left cover. See “Left cover removal (MX71x)” on page 416.
5 Remove the right cover. See “Right cover removal (MX71x)” on page 438.
6 Remove the rear lower door. See “Rear lower door removal (MX81x)” on page 552.
7 Remove the four screws (A) securing the right frame extension to the machine.
8 Release the two hooks (B).
7463
Repair information
548
