Lexmark MX71 Series - Page 393

3 Disconnect the cable (B), and remove the sensor (bin full send).
Sensor (bin full receive) removal
1 Remove the stapler left cover. See “Stapler/offset stacker left cover removal” on page 726.
2 Remove the stapler controller board. See “Stapler/offset stacker controller board removal” on page 756.
7463
Repair information
763
