Lexmark MX71 Series - Page 430

3 Disconnect the cable (A), and then release the latches to remove the sensor.
Mailbox main drive gear removal
1 Remove the mailbox left cover. See “Mailbox left cover removal” on page 798.
2 Remove the mailbox rear door. See “Mailbox rear door removal” on page 791.
7463
Repair information
800
