Lexmark Optra Series User Manual

viii Service Manual
4049-XXX
Preventive Maintenance ...............................6-1
SafetyInspectionGuide............................. 6-1
LubricationSpecifications ........................... 6-1
Scheduled Mechanical Maintenance ................... 6-3
Printhead Window Cleaning Procedure. . ............... 6-4
CleaningTheTransferRoller......................... 6-4
PartsCatalog ........................................7-1
HowToUseThisPartsCatalog ................... 7-1
Covers........................................7-2
LowerFrame...................................7-4
UpperFrame...................................7-6
Printhead ......................................7-8
Paper Feed . . .................................7-10
Paper Feed Alignment Gears .....................7-14
Paper Feed Drive ..............................7-16
Standard Paper Tray (200-Sheet) . . . ...............7-18
Paper Tray (500-Sheet). . ........................7-20
Base for Paper Drawer (500-Sheet) . ...............7-22
Second Paper Drawer, (200-Sheet) . ...............7-24
Optional Paper Drawer (500-Sheet) . ...............7-26
Fuser........................................7-28
Electronics....................................7-32
TransferRoll..................................7-36
DuplexOption.................................7-38
Envelope+ and 100-Sheet Auxiliary Feeder ..........7-40
Dual Rear Feeder ..............................7-42
High Capacity Feeder . . . ........................7-44
Options ......................................7-46
Miscellaneous .................................7-47
Index ............................................... X1

Lexmark Optra Series Specifications

General

Category	Printer
Print Technology	Laser
Max Resolution (BW)	600 x 600 dpi
Black Print Speed	12 ppm
Connectivity	Parallel
Media sizes supported	Letter, Legal, A4, A5
Memory	2 MB
Supported Operating Systems	Windows 3.1, Windows 95, Windows 98, Windows NT
