When printing on card stock:
• Set the Paper Type to Card Stock in the Paper Menu.
• Do not use card stock that is creased. It may cause paper jams.
When feeding labels, the number of labels per sheet can affect registration more than basis weight. Typically, the more
labels per sheet, the better the registration.
For more information, see the following:
• “Pick roller technology” on page 11
• “Grain orientation” on page 17
• “Maintenance procedures” on page 14
• “Troubleshooting” on page 14
Optra W810
Limit label printing to occasional use of A4‑ or letter‑size paper labels designed for laser printers. We do not recommend
using vinyl or polyester labels.
The Optra W810 supports stocks up to 163 g/m
2
(43 lb). Always feed labels and card stock from Tray 1, which holds up
to 50 sheets of labels or card stock.
The following table lists the maximum weights supported by Tray 1.
Overview of card stock and label support
Paper source
Card stock Labels
Index Bristol Tag Cover Paper Vinyl
Tray 1
163 g/m
2
163 g/m
2
—
163 g/m
2
—
For paper and transparency specifications, see the printer User's Guide.
Media specifications
Labels Width: 210–216 mm (8.3–8.5 in.)
Length: 279–356 mm (11–11.7 in.)
Weight:
120–128 g/m
2
(32–34 lb.)
Thickness: 0.13–0.20 mm (0.005–0.008 in.)
Smoothness: 100–400 Sheffield*
Printer specifications 172
